Introduction
Hammer crusher can be divided into single rotor (single-axis) and dual-rotor (two-shaft). The single rotor can be divided into two types: irreversible and reversible. According to the number of rows of hammers, it can be divided into a single row and multi row. The hammer crusher can be used not only for stone production lines, sand production lines but also for cone crushers in beneficiation lines. It is widely used in fine dressing medium hardness materials in mineral processing plants, refractory materials plants, cement plants, glass factories, electric power, metallurgy and other industrial sectors. It can be used for dry and wet crushing.
Working Principle
The material entered into the working area of the crusher is crushed by high-speed hammers. The crushed material obtains kinetic energy from the hammers, and then it impacts on the crushing plate and grate screen at high speed and is broken for the second time.
Specification
Model | Feeding Size (mm) | Descharging Size (mm) | Capacity(m³/h) | Motor Power (kw) | Total Weight(t) | Dimensions(Lx WxH) (mm) |
PC 400X300 | ≤200 | ≤25 | 5-10 | 11 | 0.8 | 900x670X860 |
PC 600X400 | ≤250 | ≤25 | 10-22 | 22 | 2.26 | 1200x1050X1200 |
PC 800X600 | ≤250 | ≤25 | 18-40 | 55 | 4.8 | 1310x1180x1310 |
PC 1000X800 | ≤350 | ≤25 | 25-50 | 75 | 5.9 | 1600x1390x1575 |
PC 1000X1000 | ≤350 | ≤25 | 30-55 | 90 | 8 | 1800x1590x1775 |
